Diameter Inches |
Diameter mm |
WLL kg |
Minimal Breaking Force MBF - kg |
| 0.472 | 12 | 2,400 | 12,400 |
| 0.591 | 15 | 3,800 | 19,400 |
| 0.709 | 18 | 5,500 | 28,000 |
| 0.827 | 21 | 6,000 | 31,100 |
| 0.945 | 24 | 9,000 | 45,800 |
| 1.063 | 27 | 10,000 | 52,700 |
| 1.181 | 30 | 14,800 | 73,900 |
| 1.299 | 33 | 11,000 | 86,900 |
| 1.417 | 36 | 17,900 | 106,000 |
| 1.535 | 39 | 21,000 | 125,000 |
| 1.654 | 42 | 25,000 | 145,000 |
| 1.890 | 48 | 29,000 | 189,000 |
| 2.126 | 54 | 47,900 | 239,000 |
| 2.244 | 57 | 53,000 | 266,800 |
| 2.362 | 60 | 59,000 | 297,800 |
| 2.598 | 66 | 72,000 | 355,000 |
| 2.835 | 72 | 77,000 | 388,000 |
| 3.071 | 78 | 90,000 | 453,600 |
| 3.307 | 84 | 110,000 | 553,000 |
3.543 |
90 | 125,000 | 626,000 |
| 3.780 | 96 | 140,000 | 704,000 |
| 4.252 | 108 | 185,000 | 928,000 |
| 4.724 | 120 | 222,000 | 1,112,000 |
| 5.315 | 135 | 285,000 | 1,425,000 |
| 5.669 | 144 | 312,000 | 1,566,000 |
Length |
On Request |
| Type of Material | On Request |
| According to | 98/37/EC, BS EN 13414-1, ASME B 30.9 |
| Safety Factor | 5 |
| Conformity Statement | Included |
| Deviating models | On Request |
