Article Nº	Diameter inches	Diameter mm	Weigth / 100m kg	Minimal Breaking Force MBF - kg
51160001	0.315	8	26	4,380
51160002	0.354	9	33	5,880
51160003	0.394	10	41	6,850
51160004	0.433	11	50	8,300
51160005	0.472	12	60	9,900
51160006	0.512	13	70	11,600
51160007	0.511	14	80	13,500
51160008	0.591	15	93	15,400
51160009	0.394	16	105	17,500
51160010	0.433	18	133	22,200
51160011	0.472	19	151	24,700
51160012	0.511	20	164	25,700
51160013	0.552	22	198	33,250
51160014	0.591	24	228	36,000
51160015	0.630	25	265	42,000
51160016	0.709	28	328	51,200
51160017	0.787	30	364	58,200
51160018	1.260	32	414	65,200
51160019	1.378	35	514	81,000
51160020	1.496	38	596	94,000
51160021	1.575	40	654	103,000
51160022	1.654	42	715	112,800
51160023	1.732	44	778	122,700
51160024	1.772	45	844	132,000
51160025	1.890	48	913	144,000
51160026	2.047	52	1060	167,000
51160027	2.126	54	1138	188,000



Class	180 / 199 kg/mm²
Theoretical Breakingforce	MBF x 1.219
Application	naval towage
Deviating models	on request
